basssub B-12deluxe



basssub B-12deluxe          basssub B-12deluxe

B-12deluxe general description

Features B-12deluxe

  • 12" speaker (4"/100mm voice coil)
  • bass reflex design
  • binding post connection
  • perforated steel front grill powder coated
  • acoustic foam 10mm
  • wood housing 1. class MDF
  • polyurea (PU) high scratch proof coating
  • high luster lacquer in black
  • optional high luster lacquer in white or colours
  • optional texture painting white or colours
  • optional plane matt painting black or white


basssub B-12deluxe

B-12deluxe specification
rated impedance (optional) 8Ω (16Ω)
power handling capacity AES/peak* 1000W / 3000W*
available frequency response** 43Hz-250Hz
max. sound pressure level*** 130dB
LF-transducer rated size 12"
LF-transducer voice coil diameter 4"/100mm
LF-transducer magnet structure ferrite
dimension w/h/d in mm 500/350/500
weight 21kg

* peak 10ms, with TD-8000 amplifier and B-12deluxe max controller setup
** -10dB with B-12deluxe FR controller setup
***1m free field, pink noise, crest factor 10dB, with TD-8000 and B-12deluxe SPL controller setup
